FHD (High Density) series MTP® fiber cassette modules offer 24-fiber MTP® adapter on the rear of the units routed to 8-fiber MTP® adapters on the front patch field, which interconnect with high density fiber cable assemblies for multiple applications. The MTP®-24 cassette enables high-density, cost-effective 10G deployments and the simplest migration to 40G, 100G, and even 400G. The cassette allows 96 fiber connections to be deployed in the FHD® series rack unit (1 RU).
SPECIFICATION
| Fiber Count | 24 Fibers |
|---|---|
| Fiber Mode | OS2 |
| Adapter Type |
US Conec MTP® |
| Adapter Color |
Black |
| Number of Front MTP® Port |
3 Ports |
| Number of Rear MTP® Port |
1 Ports |
| Key Orientation |
Opposed |
| Housing Type |
Cassette |
| Insertion Loss |
≤0.35dB |
| Return Loss |
≥60dB |
| Polarity |
Universal |
| Dimensions (HxWxD) | 1.38''x 4.29''x 6.22'' (35x 109x 158mm) |
| MTP Adapter |
Key Up to Key Down |
| Material of Cassette Body |
Aluminium (AL5052) |
| Standard |
RoHS Compliant |
| Application |
Matching for FHD Series Enclosures |
