FHD (High Density) splice cassette modules can house and protect fiber optic splices, guarantee proper fiber cable management and bend radius control, allow for clear labeling and logical organization of the fiber optic splices, and hold and protect up to 24 fusion splices. Splice cassettes eliminate the need for individual splice trays within FHD series rack mount fiber enclosures and provide optimal organization and slack management of fibers. Typical applications include Wide Area Networks (WAN), campuses, government installations, data centers, and central offices.
SPECIFICATION
| Fiber Count | 24 Fibers |
|---|---|
| Fiber Mode | OS2 9/125μm |
| Front Connector Type | LC UPC Duplex (Blue) |
| Number of LC Port | 12 Ports |
| Material of Splice Tray |
ABS |
| Housing Type |
Cassette |
| Material of Sleeve |
Zirconia Ceramic |
| Material of Cassette Body |
Aluminium (AL5052) |
| LC Pigtail Length |
50cm |
| Fiber Splice Jacket OD |
0.9mm |
| Insertion Loss |
0.3dB |
| Dimensions (HxWxD) | 1.38''x 4.29''x 6.29'' (35x 109x 160mm) |
| Standard |
RoHS Compliant |
| Application | Matching for FHD Series Enclosures |
