Description
800G FINNED-TOP OSFP TO 2X QSFP112 BREAKOUT AOC WITH CDR (TX / RX)Multimode Fiber, 1 - 100 m
- Universal Active Optical Cable (AOC) with CDR (TX / RX), 1 - 100 m
- Use 3CBOX to configure to almost any vendor
- Finned-Top OSFP to QSFP112
- PAM4 modulated signal
- Supported Datarate 850 Gbit/s
- Modules are permanently attached to each end
- Low power consumption < 34 W (less than 15 W per terminal)
- Easy cable routing thanks to small diameter (Ø 2 mm) and bend radius
- Connect different host systems by configuring each side individually
SPECIFICATION
| TYPE | AOC Breakout |
|---|---|
| FORM FACTOR | OSFP to 2x QSFP112 |
| INTERFACE | Active Optical Cable |
| CABLE TYPE | Optical Fiber |
| TEMPERATURE RANGE | 0°C - 70°C |
| BANDWIDTH | 850 Gbit/s |
| DIGITAL DIAGNOSTIC MANAGEMENT (DDM) | implemented |
| CDR | TX and RX |
| MODULATION |
PAM4 |
| SUPPORTED PROTOCOLS | 800G Ethernet, 400G Ethernet |
| POWER CONSUMPTION | 34 W (15 W + 2x 9.5 W) |
