Description
800G CLOSED-TOP OSFP AOC WITH CDR (TX / RX)Multimode Fiber, 1 - 30 m
- Universal Active Optical Cable (AOC) with CDR (TX / RX), 1 - 30
- Use 3CBOX to configure to almost any vendor
- Closed-Top OSFP to Closed-Top OSFP
- PAM4 modulated signal
- Supported Datarate 850 Gbit/s
- Modules are permanently attached to each end
- Low power consumption < 28 W (less than 14 W per terminal)
- Easy cable routing thanks to small diameter (Ø 2 mm) and bend radius
- Connect different host systems by configuring each side individually
SPECIFICATION
| TYPE | AOC |
|---|---|
| FORM FACTOR | OSFP to OSFP |
| INTERFACE | Active Optical Cable |
| CABLE TYPE | Optical Fiber |
| TEMPERATURE RANGE | 0°C - 70°C |
| BANDWIDTH | 850 Gbit/s |
| DIGITAL DIAGNOSTIC MANAGEMENT (DDM) | 28 W (14 W + 14 W) |
| CDR | TX and RX |
| MODULATION |
PAM4 |
| SUPPORTED PROTOCOLS | 800G Ethernet, 400G Ethernet, 200G Ethernet, 100G Ethernet |
