Description
6G SDI VIDEO SFP+ CWDM~40 km / 17 dB, 1270 nm - 1610 nm, LC-Duplex
- Universal SDI SFP+ Transceiver - CWDM
- Use 3CBOX to configure to almost any vendor
- CWDM for multiple applications over one duplex fiber
- Supported Data Rates: 270 Mbit/s - 5.94 Gbit/s
- Powerbudget of 17 dB for up to 40 km using an OS2 ITU-T G.652 fiber
SPECIFICATION
| FORM FACTOR | SFP+ |
|---|---|
| CONNECTOR / POLISH | LC-Duplex PC |
| INTERFACE | CWDM |
| TYPE | CWDM 6G SDI |
| DISTANCE | 40 km |
| TEMPERATURE RANGE | 0°C - 70°C |
| BANDWIDTH | 270 Mbit/s - 5.94 Gbit/s |
| DIGITAL DIAGNOSTIC MANAGEMENT (DDM) | Internally Calibrated |
|---|---|
| POWER CONSUMPTION | 1.2 W |
| CDR | none |
| INBUILT FEC | No |
| POWERBUDGET (DB) | 17 dB |
| TRANSMIT MIN/MAX PER LANE | 0 dBm / 5 dBm |
| RECEIVER MIN/MAX PER LANE | -17 dBm / 0.5 dBm (overload) |
| LASER | DFB |
| RECEIVER TYPE | PIN |
| MODULATION | NRZ |
| EXTINCTION RATIO | 3.5dB |
| SUPPORTED PROTOCOLS | 6G SDI |
