Description
40G QSFP+ LX4 150 m, λ1271-1331 nm, LC-Duplex, Single-/Multimode
- Universal QSFP+ Transceiver
- Use 3CBOX to configure to almost any vendor
- For 40GBASE-IR4 Ethernet links
- Supported Data Rates: 41.2 Gbit/s - 44.4 Gbit/s
- Up to 150 m via Multimode OM3 and 2 km via Singlemode OS2
- LC-Duplex Connector
SPECIFICATION
| FORM FACTOR | QSFP+ |
|---|---|
| CONNECTOR / POLISH | LC-Duplex PC |
| INTERFACE | Singlemode |
| TYPE | LX4 |
| DISTANCE | 150m |
| TEMPERATURE RANGE | 0°C - 70°C |
| LANE COUNT | 4 x (Tx/Rx) |
| BANDWIDTH | 41.2 Gbit/s - 44.4 Gbit/s |
| BANDWITH PER LANE | 10.3 Gbit/s - 11.1 Gbit/s |
| DIGITAL DIAGNOSTIC MANAGEMENT (DDM) | Yes, internally calibrated |
|---|---|
| POWER CONSUMPTION | 3.5 W |
| CDR | none |
| SGMII | No |
| INBUILT FEC | No |
| POWERBUDGET (DB) | 4.5 dB |
| TRANSMIT MIN/MAX PER LANE | -7 dBm / 2.3 dBm |
| RECEIVER MIN/MAX PER LANE | -11.5 dBm / 3.3 dBm (overload) |
| WAVELENGTH TX (TYPICAL) | 1271 nm, 1291 nm, 1311 nm, 1331 nm |
| WAVELENGTH TX (RANGE) | |
|---|---|
| WAVELENGTH RX (TYPICAL) | 1271 nm, 1291 nm, 1311 nm, 1331 nm |
| LASER | DFB |
| RECEIVER TYPE | PIN |
| MODULATION | NRZ |
| TRANSMIT AND DISPERSION PENALTY | |
| EXTINCTION RATIO | 3.5 dB |
| SUPPORTED PROTOCOLS | 40G Ethernet, 10G Ethernet, OTU3, OTU3e2 |
