Description
40G QSFP+ ER440 km, λ1271-1331 nm, LC-Duplex, Singlemode
- Universal QSFP+ Transceiver
- Use 3CBOX to configure to almost any vendor
- For 40GBASE-ER4 Ethernet links
- Supported Data Rates: 41.2 Gbit/s - 44.8 Gbit/s
- Up to 40 km via Singlemode OS2
- LC-Duplex Connector
SPECIFICATION
| FORM FACTOR | QSFP+ |
|---|---|
| CONNECTOR / POLISH | LC-Duplex PC |
| INTERFACE | Singlemode |
| TYPE | ER4 |
| DISTANCE | 40 km |
| TEMPERATURE RANGE | 0°C - 70°C |
| LANE COUNT | 4 x (Tx/Rx) |
| BANDWIDTH | 41.2 Gbit/s - 44.8 Gbit/s |
| BANDWITH PER LANE | 10.3 Gbit/s - 11.2 Gbit/s |
| DIGITAL DIAGNOSTIC MANAGEMENT (DDM) | Yes, internally calibrated |
|---|---|
| POWER CONSUMPTION | 3.5 W |
| CDR | none |
| SGMII | No |
| INBUILT FEC | No |
| POWERBUDGET (DB) | 18.5 dB |
| TRANSMIT MIN/MAX PER LANE | -2.7 dBm / 4.5 dBm |
| RECEIVER MIN/MAX PER LANE | -21.2 dBm / -4.5 dBm (overload) |
| WAVELENGTH TX (TYPICAL) | 1271 nm, 1291 nm, 1311 nm, 1331 nm |
| WAVELENGTH TX (RANGE) | |
|---|---|
| WAVELENGTH RX (TYPICAL) | 1271 nm, 1291 nm, 1311 nm, 1331 nm |
| LASER | DFB |
| RECEIVER TYPE | APD |
| MODULATION | NRZ |
| TRANSMIT AND DISPERSION PENALTY | 2.6 dB |
| EXTINCTION RATIO | 5.5 dB |
| SUPPORTED PROTOCOLS | 40G Ethernet, 10G Ethernet, OTU3, OTU3e2 |
