Description
400G QSFP-DD TO 4X QSFP28 BREAKOUT AOC WITH CDR (TX / RX)Multimode Fiber, 1 - 30 m
- Universal Active Optical Cable (AOC) with CDR (TX / RX), 1 - 30 m
- Use 3CBOX to configure to almost any vendor
- QSFP-DD to QSFP28
- PAM4 modulated signal
- Supports Datarates from 53.13 to 425.04 Gbit/s
- Modules are permanently attached to each end
- Low power consumption < 26 W (less than 10 W per terminal)
- Easy cable routing thanks to small diameter (Ø 2 mm) and bend radius
- Connect different host systems by configuring each side individually
SPECIFICATION
| TYPE | AOC Breakout |
|---|---|
| FORM FACTOR | QSFP-DD to 4x QSFP28 |
| INTERFACE | Active Optical Cable |
| CABLE TYPE | Optical Fiber |
| TEMPERATURE RANGE | 0°C - 70°C |
| BANDWIDTH | 425.04 Gbit/s |
| DIGITAL DIAGNOSTIC MANAGEMENT (DDM) | implemented |
| CDR | TX and RX |
| MODULATION |
PAM4 |
| SUPPORTED PROTOCOLS | 400G Ethernet, 100G Ethernet |
| POWER CONSUMPTION | 26 W (10 W + 4x 4 W) |
