100G Transponder for Multi-Service Transmission
The 2*100G OTU service board supports 2 100G service accesses, adopts advanced technologies and coherent reception, and overcomes the high-speed transmission system's requirements for OSNR, CD tolerance, PMD tolerance, and nonlinear transmission. Challenges of physical effects, it can realize 100G service over 1200 kilometers without electric relay transmission, and the line side interface supports C-band 96 wave (50GHz) tunable.
| Client Interface | QSFP28 |
|---|---|
| Line Interface | CFP2 |
| Line Interface Wavelength Range | 1528~1568nm (C-Band) |
| Client Signal Mapping Mode | 100GE/OTU4 ↔ ODU4 |
| Out-Band Management | SNMP v2, WEB |
| Operating Temperature | -10 to 60°C |
| Client Interface Protocols | 100Gbe/OTU4 |
| Line Interface Protocol |
C-Band Tunable Coherent CFP2
|
| Line Modulation | PDM-QPSK |
| Line Signal Multiplexing Structure |
(100G) ODU4 ↔ ODU2/2e, ODU4 ↔ ODU3 |
|---|---|
| Power Consumption | ＜60w |
| STORAGE TEMPERATURE | -40 to 80°C |
