10G SFP+ BIDI LR 10km, TX1270 / RX1330 nm, INDUSTRIAL


Price:
Sale price$24.50

Description

10G SFP+ BIDI LR INDUSTRIAL10 km, ᵀˣ1270 / ᴿˣ1330 nm, LC-Simplex, Singlemode

  1. Universal SFP+BIDI Transceiver
  2. Use 3CBOX to configure to almost any vendor
  3. Double your bandwith by using only one fiber for transmit and receive
  4. For 10GBASE-LR Ethernet links
  5. Supported Data Rates: 614 Mbit/s - 11.3 Gbit/s
  6. Up to 10 km via Singlemode OS2
  7. LC-Simplex Connector
  8. Operating Temperature from -40°C to 85°C

SPECIFICATION

FORM FACTOR SFP+
CONNECTOR / POLISH LC-Simplex UPC
INTERFACE Singlemode BiDi
TYPE BiDi LR
DISTANCE 10KM
TEMPERATURE RANGE -40°C - 85°C
BANDWIDTH 614 Mbit/s - 11.3 Gbit/s



DIGITAL DIAGNOSTIC MANAGEMENT (DDM) Yes, internally calibrated
POWER CONSUMPTION 1.5 W
CDR none
SGMII No
INBUILT FEC No
POWERBUDGET (DB) 4.4 dB
TRANSMIT MIN/MAX PER LANE -8.2 dBm / 0.5 dBm
RECEIVER MIN/MAX PER LANE -12.6 dBm / 0.5 dBm (overload)
WAVELENGTH TX (TYPICAL) 1270 nm



WAVELENGTH TX (RANGE) 1260 - 1280 nm
WAVELENGTH RX (TYPICAL) 1330 nm
WAVELENGTH RX (RANGE) 1320 - 1340 nm
LASER DFB
RECEIVER TYPE APD
MODULATION NRZ
EXTINCTION RATIO 3.5 dB
SUPPORTED PROTOCOLS 10G Ethernet, 10G FC, 8G Fibre Channel, Gigabit Ethernet, LTE 0.614G CPRI, LTE 0.768G OBSAI, LTE 1.22G CPRI, LTE 1.536G OBSAI, LTE 2.458G CPRI, LTE 3.072G OBSAI, LTE 4.915G CPRI, LTE 6.144G CPRI, LTE 6.144G OBSAI, LTE 7.373G CPRI, LTE 9.830G CPRI
